Carriage House Overlay Steel Garage Doors Model - 5700

Our wood garage doors embody a profound sense of history, ensuring a truly memorable experience. Meticulously constructed using premium Western Red Cedar or Fijian Genuine Mahogany boards, and fortified with a sturdy steel base, these doors artfully revive the timeless charm of wood overlay carriage garage doors. Blending classic aesthetics with modern innovation, they provide an enduring and captivating appearance that seamlessly integrates into any architectural style. Prepare to be captivated by the irresistible allure of our wood garage doors, beautifully combining tradition and contemporary design.

Carriage Door Overlay 5700 represents a specialized overlay technique employed in the creation of this series of overhead garage doors. The term “carriage door” commonly denotes the traditional swinging doors seen on carriage houses. In this context, the overlay pertains to decorative enhancements applied to the garage door’s surface, heightening its visual appeal.

Product Description: Model 5700 Steel Carriage House Door

This stunning garage door merges the rustic charm of natural wood with the strength of a steel base, delivering both beauty and performance. Each section is constructed from monolithic plank panels available in 18″, 21″, or 24″ heights and boasts a substantial 2-3/4″ thickness. The exterior face features genuine tongue-and-groove boards of either Western Red Cedar or Fijian Mahogany, meticulously adhered to a 26-gauge galvanized steel base. Accent boards in matching wood further enhance the classic carriage house look. The interior is finished with 27-gauge galvanized steel, coated in a white polyester primer and topcoat for a clean, polished finish.

Designed for exceptional energy efficiency, this door includes 1-7/8″ of CFC-free urethane insulation foamed in place between the steel skins, offering an impressive R-value of 18.03 and a U-value of 0.056. Reinforced steel end caps and hinge plates provide added durability, while tongue-and-groove joints and galvanized trussing ensure structural integrity and weather resistance. Heavy-duty hardware, including top and bottom fixtures, hinges, and ball-bearing rollers, is engineered for smooth operation and long-lasting reliability. The torsion spring system, built to ANSI 102 standards, is custom-calibrated for each door and rated for a minimum of 10,000 cycles.

To enhance curb appeal, the Model 5700 comes unfinished to allow for custom staining or painting, and includes optional decorative hardware in a Black Spade design with straps and handles for a traditional carriage house aesthetic. Optional window lites are available in polycarbonate, faux, or insulated designer glass styles such as glue chip or seeded glass. For added protection, aluminum bottom retainers and optional header and jamb weather seals are also available.

Garage Door Features: Model 5700

Trust Smart Doors for your next garage door installations. Our extensive garage door catalogue and expertise ensure that you’ll find the perfect garage door to enhance the functionality and aesthetics of your property.

2” thick CFC-free polyurethane insulated thermally broken base sections
R-value: 18.03 (R-value testing is in accordance with ASTM C518 standards)
Available in Western Red Cedar or Fijian Mahogany
The wide tongue-and-groove boards and smooth accent battens are laminated to the steel base sections with high performance adhesives. The garage door face is manufactured unfinished for field painting or staining.
Wood-grained steel interior, pre-finished in white
Square top standard; optional arched top
Faux windows are an option with the background color always being black and can be combined with all window section options
One set of spade decorative hardware is standard for all doors; optional Barcelona or Wrought Iron designs replicate an old-world look
These wood garage doors include the optional Appearance Package upgrade
